Company Capability | |
Layers | 1-22 layers |
Copper Thickness | 0.5-6 OZ |
Material | FR4(Shengyi China,ITEQ,KB A+,HZ),HI-TG, FR06,Rogers, Taconic,Argon,
Nalco,Isola and so on |
Solder Mask | green, yellow,white, blue,black,red |
Finished Surface | conventional hasl, lead free hasl, immersion gold, immersion tin,immersion silver, hard gold, OSP... |
Silkscreen color | white,black |
Products Type | HF(High-Frequency)&(Radio Frenquency)board,impendance controlled board, HDI board,BGA&Fine pitch board |
Minimum line width/gap | 3.5/4mil(laser drill) |
Minimum hole size | 0.15mm(mechanical drill)/4mil(laser drill) |
Minimum Annlar Ring | 4mil |
Max Copper thickness | 6OZ |
Min Solder Mask Bridge | 0.08mm |
Plugging Vias capability | 0.2-0.8mm |
Contact us if you need more details on Electronic Circuit Assembly. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Printed
Circuit Board Assembly、Pcb Circuit Boards. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Wireless Charging PCBA
