Company Capability | |
Layers | 1-22 layers |
Copper Thickness | 0.5-6OZ |
Material | FR4(Shengyi China, ITEQ, KB A+, HZ), HI-TG, FR06, Rogers, Taconic, Argon, Nalco, Isola and so on |
Solder Mask | green, yellow, white, blue, black, red |
Finished Surface | conventional hasl, lead free hasl, immersion gold, immersion tin, immersion silver, hard gold, OSP... |
Silkscreen color | white, black |
Products Type | HF(High-Frequency)&(Radio Frenquency)board, impendance controlled board, HDI board, BGA&Fine pitch board |
Minimum line width/gap | 3.5/4mil(laser drill) |
Minimum hole size | 0.15mm(mechanical drill)/4mil(laser drill) |
Minimum Annlar Ring | 4mil |
Max Copper thickness | 6OZ |
Min Solder Mask Bridge | 0.08mm |
Plugging Vias capability | 0.2-0.8mm |


PCB Board we have produced are mainly used in industrial control, medical treatment, automobile area ,LED lighting, communication ,aviation and so on. All PCBs are ISO9001, ROHS, UL certificated and meet the international IPC standard.


| HDI PCB Boards contain blind and/or buried vias and often contain microvias of 4mil or less in diameter. They have a higher circuitry density than traditional circuit boards. |
| The general TG plate is more than 130 degrees, the medium TG is generally greater than 150 degrees, and the medium TG is more than 170 degrees. |
| RO4003C, RO4350B, RO3003, Tachic RF-35 ISOLA FR-406 in the range from 500MHz to 2GHz, products are applied to power devider, radar, satellite system, mobile phone reception base station and so on.
|
| As carbon ink pcb has very good resistance value that will help supply good conductivity. Carbon ink pcb is widely used in automotive filed, medical electronics, communication equipment and so on. |
| Polyimide(sometimes abbreviated PI)is a polymer of imide monomers which is one of the best synthetic organic polymers. Because of good heat resistance, mechanical strength and insulative properties polyimide material is most commonly used in the flexible printed circuit boards. |
| Thick copper PCBs or heavy copper PCBs are characterised by structures with copper thicknesses more than 70um. These PCBs are used for large(high) current out puts and for optimisation of the thermal management. The thick copper allows large PCB-cross-sections for high current loads and encourages heat dissipation. |



POE has the capability to manufacture pcb ranging from basic single sided boards up to twenty-two layer multilayers ,and provide one stop turnkey services, including pcb layout, manufacture, assembly, components sourcing and function testing. The superior service we offer our customers is the key to our success and our mission has remained the same since we started business in 1996: to provide the best and fastest service for the continuous innovation of electronic technology. This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers PCB requirements– from front end engineering through to in time deliveries.





PCB
| | | Mass productions
(above 30 m2 ) |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
PCB Assembly | | The fastest Delivery Date |
| | |
| | |
Medium Volum(100-1000 pcs) | | |
Mass productions (>1000 pcs) | | |


Q1.What is needed for PCB
PCBA quotation?
A: PCB: Quantity, Gerber file and Technic requirements(material, surface finish treatment, copper thickness, board thickness and so on)
PCBA: PCB information, BOM, (Testing documents)
Q2. What file formats do you accept for PCB PCBA production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.
Q4. MOQ?
A: There is no MOQ in POE. We are able to handle small as well as large volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

Contact us if you need more details on Electronic Pcb
Printed Circuit Board. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Layers Pcb、Pcb Assembly. If these products fail to match your need, please contact us and we would like to provide relevant information.
